Screen reader users will see links on a page listed without context,
so you should ensure the same link text is not used to point to different web
addresses.

For example:

```html
<p>
    Learn the latest about our products:
    <a href="/products/news">News</a>
</p>

<p>
    Learn the latest about our services:
    <a href="/company/news">News</a>
</p>
```

To a screen reader who is listing links, they will only hear:

* News
* News

These links appear to be the same, but they both behave differently.
One solution, which doesn't require the page design to change, is to add an
`aria-label` for each link:

```html
<p>
    Learn the latest about our products:
    <a href="/products/news" aria-label="Product news">News</a>
</p>

<p>
    Learn the latest about our services:
    <a href="/company/news" aria-label="Company news">News</a>
</p>
```

Which will be heard as:

* Product news
* Company news

To pass this checkpoint, make sure that links which point to different pages
have distinct text inside them, or that they specify ARIA labels (`aria-labelledby` or
`aria-label`), or they use hidden text only visible to screen readers
(e.g. `<span class="sr-only">...</span>`) to distinguish them from each
other.

If links point to the same page (e.g., they redirect or use tracking
parameters, but are functionally equivalent to the user) you can ignore
this issue.

a-duplicate-link-text-for-different-destinations

To comply with WCAG AA, the colour of text must sufficiently contrast with
its background color, so that people with moderate visual impairments can read it.

The [contrast ratio](https://www.w3.org/TR/UNDERSTANDING-WCAG20/visual-audio-contrast-contrast.html#contrast-ratiodef)
must be at least 4.5:1 for body text, and 3:1 for large text.

A much more demanding version of this check (1.4.6) exists for WCAG AAA. Ignoring an issue in this check
will also ignore it in that check, and vice versa.

aa-text-contrast

To comply with the strictest accessibility standard (WCAG AAA), the colour of text must
strongly contrast with its background color, so that people with significant visual impairments
can read it.

The [contrast ratio](https://www.w3.org/TR/UNDERSTANDING-WCAG20/visual-audio-contrast-contrast.html#contrast-ratiodef)
must be at least 7:1 for body text, and 4.5:1 for large text.

A far less demanding version of this check (1.4.3) exists for WCAG AA. All websites should aim to
meet the easier AA standard at a minimum. The AAA standard is desirable but far more challenging,
and may not be practical for your website.

aaa-text-contrast

Links must be defined in a specific way to be accessed by screen readers, which are used by
blind and the partially-sighted.

To work with accessibility technologies, links must contain both machine-readable text, and
a `href` attribute. If a link is not actually
pointing to a page or part of a page, it should be replaced with another semantic element, such
as a `button`, or the `<a>` tag should have a role of `button`.

For example:

```html
<a href="/about">About us</a>
```

If the link contains _nothing but an image_, that image should specify alternative text, e.g.

```html
<a href="/apple">
    <img src="apple.png" alt="Apple">
</a>
```

Before HTML5, an anchor was often used to create a target to link to, e.g.

```html
<a name="example"></a>
```

This is not supported in HTML5, and the use of anchors for targets is discouraged. Use an `id`
attribute on a non-anchor tag instead, e.g.

```html
<div id="example"> ... </div>
```

Empty links (e.g. `<a></a>`) are often incorrectly used for buttons or controls in a
JavaScript application. In these cases, you should usually define the link as having a more appropriate
role, e.g. as a button. To do this, use the `role` attribute (e.g `<a role="button">`), or replace
the `<a>` tag with a more appropriate tag, such as `<button>`.

For more details, see [Technique H91](https://www.w3.org/TR/2016/NOTE-WCAG20-TECHS-20161007/H91)
and learn about [ARIA roles](https://www.sitepoint.com/how-to-use-aria-effectively-with-html5/).

bad-anchor

Radio buttons or check boxes with the same name attribute must be contained
within a fieldset element.

contain-radio-or-checkbox-with-same-name

Two adjacent links should not point to the same destination. You almost always want to combine the
two links.

For example, it is quite common to link an image and text together like this:

```html
<a href="news.html">
    <img src="photo.jpg" alt="" />
</a>
<a href="news.html">
    News
</a>
```

These adjacent links should be combined like so:

```html
<a href="news.html">
    <img src="photo.jpg" alt="" />
    News
</a>
```

Links to `#` are ignored, as these are nearly always placeholders for JavaScript, e.g.:

```html
<a href="#" onclick="approve()">
    OK
</a>
<a href="#" onclick="reject()">
    Cancel
</a>
```

# Justification

Many users of assistive technology are only able to experience content sequentially - that is, they must
step through each part of the page, one part at a time. Often this is a slow process, potentially
hampered by a physical impediment.

Stepping through redundant links is time consuming; for example users of a screen reader must
hear each link read aloud in turn.

This also simplifies your code.

# Methodology

1. Find all links (`<a>` tags) on the page.
2. Ignore links pointing to `#`, as these are usually placeholders for JavaScript.
3. Flag links which are (a) separated only by whitespace and (b) which point to the
   same absolute URL.

# Learn more

Read about [Technique H2](https://www.w3.org/TR/WCAG20-TECHS/H2) on how to combine
an adjacent image and texts links.

duplicate-adjacent-link

All `id` attributes on a page must be unique, or accessible technologies used by the page
can stop working.

## Example

The duplicate `id` here makes it unclear which label belongs to which input field:

```html
<label for="name">Your name</label>
<input id="name">

<label for="name">Company name</label>
<input id="name">
```

As a result, accessible technologies like screen readers can fail to read out the
correct text, or may read out no text at all.

Similar issues can occur when using `aria-labelledby` and `aria-describedby`.

## How to fix

Ensure all `id` attributes on a page are unique.

## More information

See [Technique H93](https://www.w3.org/TR/2016/NOTE-WCAG20-TECHS-20161007/H93)
for more information.

duplicate-id

Heading elements (`<h1>`, `<h2>`, ...) must contain some machine-readable
text content.

Heading should never be empty, or just contain whitespace:

```html
<h1>   </h1>
```

Headings which contain images or other media must specify alternative text:

```html
<h1>
    <img src="heading.png" alt="Press releases">
</h1>
```

See [Technique H42](https://www.w3.org/TR/WCAG20-TECHS/H42) for more details.

empty-heading-content

All interactive components on a page, such as buttons or menus, should be far enough apart
from other interactive areas, to avoid them being used by mistake.

This ensures people with motor impairments can easily click or tap on the right element.

## How to fix

* Ensure all interactive elements are at least 24 CSS pixels wide and tall
* OR ensure there is at least 24 CSS pixels (minus the width and height of the element)
  between each interactive element

## Methodology

This check is run on both the mobile and desktop versions of every page. Results
for each may differ.

1. All interactive elements are identified, including buttons, links, and form controls.
2. If an element is not normally visible, it is ignored. This includes elements which
   are positioned offscreen or cropped (e.g. for 'screen-reader only' text).
3. If an element is larger than 24 CSS pixels in both dimensions, it passes.
4. Otherwise, the element is compared to all other elements on the page.
5. The minimum horizontal gap between the element is calculated as 24 CSS pixels,
   minus the width of the element.
6. The minimum vertical gap between the element is calculated as 24 CSS pixels,
   minus the height of the element.
7. If another element falls within the minimum horizontal or vertical gap, the
   element fails, unless both are links that point to the same place.

## Further reading

* [Target Size (Minimum)](https://www.w3.org/WAI/WCAG22/Understanding/target-size-minimum.html)
* [Technique C42 - Using min-height and min-width to ensure sufficient target spacing](https://www.w3.org/WAI/WCAG22/Techniques/css/C42)

ensure-minimum-target-size

All interactive components on a page, such as buttons or fields, should ideally be large enough
to be easily used by people with motor impairments.

This ensures people with motor impairments can easily click or tap on the element.

The recommended size is 44 x 44 CSS pixels, with some exceptions:

* **Equivalent available** - the functionality provided by
  the control is available elsewhere, and large enough, on the same page.
* **Inline text** - the control appears inside a sentence or block of text.
* **User Agent control** - the size of the target is determined by the user agent
  and is not modified by the author. Generally this is not the case for web content.
* **Essential** - the size of the target is essential to the information being conveyed,
  e.g. a tutorial demonstrating what a small button looks like. This exception is rare.

## Applying this check

Nearly all websites will fail this check by default. The minimum size requirement
is larger than most links and controls on most websites.

This is the much stricter version of the WCAG 2.2 AA check for target size. Most websites
should focus on the AA check before considering this AAA check:

* [Target Size (Minimum)](https://w3c.github.io/wcag/understanding/target-size-minimum.html)

## Methodology

This check is run on both the mobile and desktop versions of every page. Results
for each may differ.

1. All interactive elements are identified, including buttons, links, and form controls.
2. If an element is preceded or followed directly by a non-empty text node, the control
   is ignored.
3. If an element is not normally visible, it is ignored. This includes elements which
   are positioned offscreen or cropped (e.g. for 'screen-reader only' text).
4. If an element is a link, and another visible link on the page points to the same URL, with
   that other link meeting the size requirements, the element is ignored.
5. Otherwise, the element must have a minimum size of 44 x 44 CSS pixels.

## Troubleshooting

Silktide only records the first 100 instances of a failure on a page. Because failures
of this check are common, it is possible that your page has more than 100 failures, but
only the first 100 will be shown.

## Further reading

* [Target Size (Enhanced)](https://www.w3.org/WAI/WCAG22/Understanding/target-size-enhanced)

ensure-reasonable-target-size

When viewed on small screens (like mobile phones) content should be large enough to
read without being zoomed-into and scrolled in two dimensions.

WCAG 2.1 specifically requires this for:

+ Vertical scrolling content at a width equivalent to 320 CSS pixels
+ Horizontal scrolling content at a height equivalent to 256 CSS pixels

This issue almost always indicates that the webpage has not been designed
to work on mobile devices at all.

extreme-zoom-scrolling

People using screen readers are not able to see the layout of a form. To make forms
accessible, they must define explicit text labels for each form control.

Usually the best solution is to use a `<label>` element. The label may be linked to
by the form control:

```html
<label for="name">Full name</label>
<input type="name" id="name">
```

or the `<label>` can be wrapped around the form control:

```html
<label>
    Full name <input type="name">
</label>
```

Buttons are different, as their labels are specified by the code for the button, e.g.

```html
<input type="submit" value="Send message">
<button>Send message</button>
```

Alternatively ARIA attributes, such as `aria-label` may be used, but this information
will not be conveyed to visual users. For more information, see [W3C's guide to labeling controls](https://www.w3.org/WAI/tutorials/forms/labels/).

Hidden input fields (`<input type="hidden">`) do not require labels.
Note that the `placeholder` attribute
[should not be used as an alternative to a label](https://www.w3.org/TR/html/sec-forms.html#the-placeholder-attribute),
nor should the `title` attribute.

## Custom roles

Note that this check considers the underlying accessible role of an element, which can be
different from the tag itself.

For example, this `<div>` has a `role` of `button`, and so is expected to have a label, like
a button would.

```html
<div role="button"></div>
```

form-control-labels

To comply with WCAG 2.1, fields must identify what their purpose is _programmatically_. If done correctly,
this allows browsers to help users fill in forms with known information, such as their name and email address.

This is accomplished via the `autocomplete` attribute, which should be set to a
[supported value](https://developer.mozilla.org/en-US/docs/Web/HTML/Attributes/autocomplete) wherever
appropriate, e.g.

```html
<label for="name">
  First Name
</label>
<input id="name" type="text" autocomplete="given-name">
```

For fields where `autocomplete` is not appropriate, e.g. due to security, or the field not matching the
specification, the specific field should be ignored.

## Methodology

* All fields which could support `autocomplete` (e.g. text fields)
  are checked. Other fields - like dropdown menus - are ignored.
* The [accessible name](https://www.w3.org/TR/accname-1.2/) of each field is considered. In most cases this
  will be the `<label>` for the field.
* If the name matches a known pattern the field
  must have an appropriate `autocomplete` value specified.
  For example, an `<input>` with type `text` with a label of
  "First Name" would be expected to have an autocomplete value
  of `given-name` or similar.

Note that using `autocomplete="on"` is not sufficient to pass this check, a
specific named autocomplete value must be used. See the
[supported values](https://developer.mozilla.org/en-US/docs/Web/HTML/Attributes/autocomplete).

## Troubleshooting

If a field is a false positive, check whether the field has an
appropriate accessible name (i.e. a `<label>` or `aria-label`).

If the label is incorrect, Silktide may assume that the field
requires `autocomplete` where it does not. You should fix the
label to avoid this.

Otherwise, you can simply ignore the specific field.

## More information

* [How to use HTML 5.2 attributes](https://www.w3.org/WAI/WCAG21/Techniques/html/H98)

identify-input-purpose

An `<img>` element inside a link must not specify alternative text that duplicates the
content of a text link inside or beside it.

For example, this code should be avoided:

```html
<a href="/apple">
    <img src="apple.png" alt="Apple">
    Apple
</a>
```

Accessible technologies will tend to see this as "Apple Apple". The correct behaviour is to
specify either a null (empty) `alt` attribute:

```html
<a href="/apple">
    <img src="apple.png" alt="">
    Apple
</a>
```

or to hide the image via `aria-hidden`:

```html
<a href="/apple">
    <img src="apple.png" aria-hidden="true">
    Apple
</a>
```

# Learn more

Read about [Technique H2](https://www.w3.org/TR/WCAG20-TECHS/H2) on how to combine
an adjacent image and texts links.

See the [WAI Tutorial on decorative images](https://www.w3.org/WAI/tutorials/images/decorative/).

img-duplicate-alt

Links must be appear visually distinct from regular text. A common mistake is to make links
only differ subtly in color. Users with visual impairments cannot see these links.

There are two ways to comply with this requirement:

1. You can make links appear differently from regular text without relying on color alone.
   For example, you can add an underline to your links. This makes links easy to identify, even
   to people who cannot see color at all.
2. You can make links a color which is very different from the surrounding text (a 3:1 ratio),
   AND ensure that when the link is selected with the keyboard or mouse that it appears
   differently from regular text without relying on color alone.

Unless you have disabled the `outline` CSS style, links will automatically appear visually distinct
when selected with the keyboard.

link-contrast

The purpose of a link should be clear from the text inside the link. Links like "learn more" are
not helpful to users with assistive technology.

Links should also avoid redundantly saying that they are links, e.g. "link to page" as screen
readers will read these out with the word "link" added, e.g. "link link to page".

Exceptions to these rules are allowed where the purpose of a link would be ambiguous to users
in general.

link-purpose-a

Avoid opening links in a new tab or window. Where you must do this, include an explanation
in the text of the link.

## Why this matters

Opening links in a new tab or window breaks the back button and can be disorientating for
novice web users, and the visually impaired. Generally you should avoid opening links in a
new tab or window, but if you have to, you should include text explaining that this will happen.

## How to fix

An explanation must be clear in the accessible text for the link. For example:

```html
<a href="products.html" target="_blank">
    Products (opens in new window)
</a>
```

Or, for an image inside a link:

```html
<a href="products.html" target="_blank">
    <img src="products.jpg" alt="Products (opens in new window)">
</a>
```

Rather than updating all of your links manually to do this, you can add a simple CSS
selector, such as:

```css
a[target="_blank"]:after {
    content: " (opens in new window)";
}
```

Note that doing this with an icon, is not sufficient to pass this check. The text must be
readable by screen readers.

Alternatively you can override the link text for accessible technologies (like screenreaders),
so that the appearance of the link does not change. For example:

```html
<a href="products.html" target="_blank" aria-label="Products (opens in new window)">
    Products
</a>
```

Note that if you do this, the `aria-label` will replace the text content of the link completely,
so it must still make sense in isolation.

## Terminology

Although it is common to say "opens in new window", almost all browsers now use tabs, and
so this terminology is potentially confusing. You may prefer: "opens in new tab".

## Methodology

1. Silktide considers all links on a page with a `target` attribute of `_blank`.
2. For each link, Silktide considers the screen-readable text of the link, which includes:
   * The text content of the link
   * Any `alt` text inside any images inside the link
   * Any `aria-label` or `aria-labelled-by` text
   * The `content` of the pseudo-elements `:before` and `:after`
3. This text is analysed for the presence of common text, including "opens new tab"
    and "opens new window". If the text is not found, the link fails the test.

## Further reading

Generally best practice is to avoid opening links in a new tab or window.

The W3C provides detailed guidance on
[when opening a link in a new window may be appropriate](https://www.w3.org/TR/WCAG20-TECHS/G200.html).

link-text-explains-open-in-new-window

Every page should have a clearly defined heading, known as a "H1" (Heading 1).

A `H1` is the main heading of the page. It helps accessibility by allowing uses to
skip to the main content of the page. It helps all users identify what the page is about.
It helps SEO by giving special emphasis to the topic of the page.

It is not enough to simply include large text. Headings must be coded
[semantically](https://html.com/semantic-markup/) as `<h1>` tags, like so:

```html
<h1>This is a heading</h1>
```

Note that headings must contain some machine readable text to be considered valid.
For example, this heading is not valid:

```html
<h1>
    <img src="company-logo.png">
</h1>
```

But with the addition of `alt` text, this heading is valid:

```html
<h1>
    <img src="company-logo.png" alt="About Company Inc.">
</h1>
```

Generally we recommend you just use plain text for your headings.
See [Technique H42](https://www.w3.org/TR/WCAG20-TECHS/H42) for more details.

missing-h1

Form controls must appear sufficiently distinct from their surroundings, so that people
with visual impairments are still able to clearly see them.

Either the border or the form control itself must have a 3:1 colour contrast with the
surrounding area.

## Methodology

* All `<input>`, `<textarea>`, and `<select>` elements are checked.
* For `<input>` elements, these types are ignored as their
  appearance is controlled by the browser or operating system:
  `checkbox`, `radio`, `submit`, `reset`, `image`, `hidden`, `file`.
* The flattened background color of the control is determined. This is the color of the
  control itself, combined with any parent elements if the control is transparent.
* If the control has a border or outline:
  * The flattened background color of each edge is determined.
    This is the color of the edge itself, combined with any parent elements
    if the edge is transparent.
  * If any edge has sufficient contrast with the flattened background color of the control,
    the control is considered to have sufficient contrast.
* If the control does not have a border or outline:
  * The flattened background color of the surrounding
    area is determined. This is the color of the first control's parent element which is at least
    one pixel larger around the element in every dimension, i.e. above, below, left, and right.
  * If the background color of the element has sufficient contrast with surrounding area color
    the control is considered to have sufficient contrast.

## Troubleshooting

There are some limitations to the contrast checker:

* The use of drop shadows, glowing effects, gradients, and other complex effects
  mean there is no one clear color to determine the contrast ratio against.
  In these cases, the contrast ratio cannot currently be determined.
* It is possible for an element to be positioned over multiple elements, e.g. via
  `position: absolute` or `position: fixed`. In this case, the contrast ratio cannot
  currently be determined.

## Further reading

* [WCAG 1.4.11](https://www.w3.org/WAI/WCAG21/Understanding/non-text-contrast.html)

non-text-contrast

Ensures that headings in PDF documents follow a logical hierarchical order for accessibility.

## What this means

Headings in a PDF should be arranged in a logical sequence, much like a table of contents in a book. This means using a consistent hierarchy of heading levels (like Heading 1 for main titles, Heading 2 for subsections, etc.). Headings should not skip levels abruptly (e.g., jumping from Heading 1 directly to Heading 3).

## Why it matters

1. **Accessibility**: Screen readers rely on a logical heading structure to navigate content, making it essential for users with visual impairments.
2. **Readability and Navigation**: A well-structured document with logically ordered headings enhances readability and allows all users to navigate the content more efficiently.
3. **Consistency and Professionalism**: Logical heading order reflects a professional approach to document creation and helps maintain consistency across documents.

## How to fix

1. **Review Heading Levels**: Check your document to ensure that headings follow a sequential order without skipping levels.
2. **Modify Headings**: If any headings are out of order, adjust them using your PDF editing tool to align with the logical structure.

## Testing Methodology

Silktide's checks your PDF to identify the sequence of headings. It flags PDFs where the heading order is not
hierarchical (e.g., a Heading 3 directly following a Heading 1).

Headings in a PDF should follow the sequence Heading 1 > Heading 2 > Heading 3 without skipping intermediate headings.
It is acceptable to 'go back' to previous styles/headings but the sequence should then continue without missing headings.

### Limitations
- **Contextual Analysis**: Silktide might not fully grasp the context behind the document's structure, so manual review is recommended for complex documents.
- **Styling Variations**: Variations in styling that are not properly tagged might not be detected accurately.

## Further Reading

- [Understanding WCAG: Headings and Labels](https://www.w3.org/WAI/WCAG21/Understanding/headings-and-labels.html)
- [How to Organize PDF Content with Accessible Headings](https://www.adobe.com/accessibility/pdf/pdf-accessibility-overview.html)

pdf-headings-order

Ensure that long PDF documents incorporate bookmarks to facilitate easy navigation.

## What this means

In the context of PDFs, bookmarks are navigational tools that act like an interactive table of contents.
They allow users to quickly jump to specific sections, chapters, or points of interest within the document.
This feature is particularly important in longer PDFs, where scrolling through the entire document to find
specific information can be time-consuming and inefficient.

## Why it matters

1. **Accessibility**: For users with disabilities, especially those using screen readers, bookmarks provide a way to navigate through the document without having to linearly read through all the content.
2. **User Convenience**: Bookmarks significantly enhance the user experience by allowing quick access to different sections of the document.
3. **Efficiency**: In professional or academic settings, bookmarks help in referencing and reviewing long documents more efficiently.

## How to fix

1. **Identify Key Sections**: Determine the main sections or chapters of your PDF that would benefit from bookmarks.
2. **Create Bookmarks**: Use a PDF editing tool to create bookmarks at these key sections. Ensure that the bookmarks are clearly labeled to accurately reflect the content they link to.
3. **Organize Hierarchically**: If your document has sub-sections, consider creating a hierarchical structure in your bookmarks for better organization.

## Testing Methodology

Silktide scans the PDF to identify the presence of bookmarks in documents exceeding 21 pages.

WCAG guidelines do not specify how many pages are required to be classified as a
long PDF. Because of this Silktide treats PDFs of 21 or more pages as long.
This matches [Adobe Acrobat's](https://helpx.adobe.com/acrobat/using/create-verify-pdf-accessibility.html?trackingid=KACNN#Bookmarks)
interpretation.

### Limitations
- **Page Threshold**: Silktide uses a predetermined page count to trigger this check, which may not always align with the user's definition of a 'long' document.
- **Bookmark Relevance**: While Silktide can detect the presence of bookmarks, it does not assess their relevance or accuracy in representing the document's content.

## Further Reading

- [WCAG - PDF2](https://www.w3.org/TR/WCAG20-TECHS/pdf.html#PDF2)

pdf-long-document-requires-bookmarks

Ensure that PDF documents specify a default language, so that assistive technologies can accurately
interpret their contents.

## What this means

Specifying a default language for a PDF means setting the primary language in which the document's content is written.
This setting informs users and assistive technologies about the language the content is presented in, aiding in
proper interpretation and pronunciation.

## Why it matters

1. **Accessibility**: Screen readers rely on language settings to provide correct pronunciation, making it essential for non-native speakers and individuals using text-to-speech software.
2. **User Experience**: Specifying the language helps in providing a better reading experience as it enables features like spell check and grammar tools to function correctly.
3. **Global Compliance**: Setting a default language is a requirement under various international accessibility standards, like the Web Content Accessibility Guidelines (WCAG).

## How to fix

1. **Check Document Properties**: Open the document properties in your PDF editor and navigate to the language setting.
2. **Set the Default Language**: Choose the appropriate language from the list provided or enter it manually if it's not listed.

## Testing Methodology

Silktide analyzes the document properties of the PDF to verify if a default language is specified.

### Limitations
- **Language Accuracy**: While Silktide can detect the presence of a language setting, it does not assess the accuracy of the language in relation to the document's content.
- **Multilingual Documents**: For documents containing multiple languages, Silktide might only detect the primary language set in the document properties.

## Further Reading

- [WCAG PDF 16](https://www.w3.org/TR/WCAG20-TECHS/pdf.html#PDF16)
- [Setting Language in PDF Documents](https://www.adobe.com/accessibility/pdf/pdf-accessibility-overview.html)
- [Understanding WCAG: Language of Page](https://www.w3.org/TR/UNDERSTANDING-WCAG20/meaning-doc-lang-id.html)

pdf-missing-default-language

Ensure that PDF documents specifies headings for accessibility.

## What this means

Specifying headings in a PDF involves clearly defining tagged heading elements within
the document. These headings are used to structure the content, similar to how headings
are used in web content (like HTML).

## Why it matters

1. **Accessibility**: Headings are crucial for screen readers and other assistive technologies. They allow users with visual impairments to navigate the document more easily.
2. **Document Structure**: Clearly defined headings help in organizing the content, making it more understandable and navigable for all users.
3. **Search Efficiency**: Proper headings improve the document's searchability, enabling users to find information more quickly.

## How to fix

1. **Use Styles in Document Creation**: When creating a document, use heading styles (like Heading 1, Heading 2, etc.) in your word processor before converting it to a PDF.
2. **Edit Existing PDFs**: If your PDF is already created, use a PDF editor to add or modify heading tags. Ensure that the headings are in a logical hierarchical order.

## Testing Methodology

Silktide flags PDFs that don't contain a single tagged heading.

## Further Reading

- [WCAG PDF9](https://www.w3.org/TR/WCAG20-TECHS/pdf.html#PDF9)
- [Creating Accessible PDFs](https://www.adobe.com/accessibility/pdf/pdf-accessibility-overview.html)
- [PDF Accessibility - Defining PDF Accessibility](https://www.webaim.org/techniques/acrobat/)

pdf-missing-headings

PDF documents must be tagged to ensure accessibility and compliance with digital standards.

## What this means

Tagging in a PDF involves adding hidden metadata that outlines the structure and content of the document. These tags function similarly to HTML tags, describing elements like headings, paragraphs, lists, and tables. They are crucial for screen readers and other assistive technologies to interpret the content correctly.

## Why it matters

1. **Accessibility**: Tagging makes PDFs accessible to individuals with disabilities, allowing assistive technologies to read and navigate the document effectively.
2. **Legal Compliance**: Various laws and regulations require digital content, including PDFs, to be accessible. Failure to comply can lead to legal complications.
3. **Usability**: Tagged PDFs are more user-friendly, providing better navigation and search capabilities for all users.

## How to fix

1. **Use Tag-enabled PDF Creators**: Create or convert documents using software that supports tagging, like Adobe Acrobat or Microsoft Word.
2. **Manually Add Tags**: If your PDF isn't tagged, use a PDF editor's accessibility tools to add tags. This includes setting a logical reading order and adding alternative text for images.
3. **Consult Guidelines**: Follow best practices outlined in WCAG or similar guidelines for effective tagging.

## Testing Methodology

Silktide looks at the PDF and flags it if it doesn't contain tags.

## Further Reading

- [Adobe's Guide to PDF Accessibility](https://www.adobe.com/accessibility/pdf/pdf-accessibility-overview.html)

pdf-must-be-tagged

Ensure each PDF document has a formally defined title.

## What this means

A PDF title, typically found in the document properties, acts as the official name of the document. This title is used by screen readers and other assistive technologies to provide a clear understanding of the document's content at the outset. It's different from any title or heading text that might appear within the content of the PDF itself.

## Why it matters

1. **Accessibility**: Screen reader users often hear the document title first when they open a PDF. A clear, descriptive title helps them understand what the document is about.
2. **Searchability and Organization**: A proper title makes it easier to search for and organize documents on a computer or network.

## How to fix

1. **Set the Title in Document Properties**: In your PDF editor, access the document properties section and ensure there is a title that accurately reflects the content of the PDF.
2. **Use Descriptive Titles**: Avoid vague titles. Instead, choose titles that clearly and concisely convey the subject or purpose of the document.

## Testing Methodology

Silktide checks the document properties of a PDF to verify that a title is
specified and not empty.

### Limitations
- **Title Relevance**: While Silktide can detect the presence of a title, it does not evaluate the title's relevance or accuracy in representing the document's content.

## Further Reading

- [WCAG - PDF 18](https://www.w3.org/TR/WCAG20-TECHS/PDF18.html)
- [Setting Titles in PDF Documents](https://www.adobe.com/accessibility/pdf/pdf-accessibility-overview.html)

pdf-no-title

All PDFs must define a descriptive title.
See [PDF 18](https://www.w3.org/TR/WCAG20-TECHS/PDF18.html) for details.

pdf-weak-title

wcag-22.score

wcag-22-a.score

wcag-22-aa.score

wcag-22-aaa.score

website.pages

website.documents

All field sets should contain a legend which describes its contents.

A field set is a group of form controls, such as radio buttons, checkboxes, or text fields. The
`<fieldset>` element is used to group these controls together, and the `<legend>` element is used to
describe the contents of the field set.

Whenever the `<fieldset>` element is used, it must contain a valid `<legend>` element, which
describes the contents of the field group.

## Further reading

See [how to provide a description for groups of form controls using fieldset and legend elements](https://www.w3.org/TR/WCAG20-TECHS/H71).

add-legend-to-fieldset

When an image is the only content of a link, it should specify alternative text,
via an `alt` attribute. The alternative text should describe the purpose of the link.

Without this, some users will be unable to determine what a link does, for example anyone
using a screen reader.

To fix this, simply add an `alt` attribute to the image inside the link, e.g.:

```html
<a href="/apple">
    <img src="apple.png" alt="A red apple">
</a>
```

img-in-link-missing-alt

Labels with a `for` attribute should point to the unique ID of a [labelable
control](https://developer.mozilla.org/en-US/docs/Web/Guide/HTML/Content_categories#Form_labelable)
that is used within the document.

## Why this matters

Form controls must define labels. This allows users of assistive technologies,
such as screen readers, to know what the purpose of a form control is.

If a label uses an invalid `for` attribute (i.e. one which is missing, or duplicated,
or points to something that is not labelable), that field will not be usable by assistive
technologies.

## How to fix

The `<label>` element should specify a `for` attribute that points to a
labelable control element. This error can occur if you point to a
non-labelable component, or if you don't point to a component that exists.
See [Technique H44](https://www.w3.org/WAI/WCAG21/Techniques/html/H44).

Example:

```html
<label for="name">Name</label>
<input type="text" id="name" />
```

Alternatively, if you need to point to a component that doesn't accept a label
(e.g. a `<div>`), consider using the `aria-labelledby` attribute instead.
See [Technique ARIA16](https://www.w3.org/WAI/WCAG21/Techniques/aria/ARIA16).

Example:

```html
<h2 id="price-label">Minimum price</h2>
<div role="slider" aria-labelledby="price-label"></div>
```

## Further reading

* [WCAG 1.3.1](https://www.w3.org/WAI/WCAG21/Understanding/info-and-relationships.html)

remove-for-attribute-which-does-not-exist

Do not link to an anchor on the page that does not exist. For example:
linking to `#content` without a valid destination such as `<body id="content"></body>`.

A common web design pattern is to use a named anchor to show an element via JavaScript, e.g.

```html
<a href="#foo" onclick="$('.bar').toggle();">Click me</a>
<div class="bar">
    This is some content.
</div>
```

In these cases, the anchor (`#foo`) should point to the `id` of the hidden element:

```html
<a href="#foo" onclick="$('#foo').toggle();">Click me</a>
<div id="foo">
    This is some content.
</div>
```

This way the semantic intent of the link is preserved, even without JavaScript.
Note that doing so may require modification to your script, to prevent automatic
scrolling to the named anchor.

linking-to-anchor-on-page-that-does-not-exist

Each page should have a well-defined page title (as defined by a single `<title>` tag).

add-page-title

All frames must define a readable title, which briefly described the contents of that frame.

Note that this is not the same as a `<title>` tag inside the iframe, which is insufficient.
You must provide a meaningful description for the frame using the `title` attribute.

Examples:

```html
<iframe title="Advertisement" src="ad.html">
```

```html
<frame title="Advertisement" src="ad.html">
```

# Why this matters

Accessible technologies such as screen readers rely on the `title` attribute to list
the frames on a given page.

Without a title, it is impossible to know what the frame contains, and the user must
navigate inside it, and explore the contents of the frame to figure this out.

Often iframes are used for technologies like banner ads, videos, or chat widgets. The
absence of a `title` makes these areas of the page much harder to identify, understand,
or use.

# How titles are tested

Frames which are not presented to screen readers are ignored. This includes invisible
frames, and frames marked with `aria-hidden`.

A `title` attribute must contain meaningful text, e.g. numbers / letters, to be considered
valid. A title containing just spaces, or non-readable text (e.g. an emoji) will
be flagged as invalid.

# More information

Learn about [Technique H64](https://www.w3.org/WAI/WCAG21/Techniques/html/H64)
as part of [SC 2.4.1 - Bypass Blocks](https://www.w3.org/WAI/WCAG21/Understanding/bypass-blocks).

has-frame-title

Every page should precisely specify what language(s) it is written in.

## Why this matters

Screen readers, which read out the text on a page, need to know the language to
pronounce it correctly. Without the language, text may sound like gibberish.

For example: imagine a computer pronouncing just one German word
"die" (pronounced "dee") using English pronunciation. Now extend that to every
word on the page.

Search engines may also use the language to classify pages, so this can have
an effect on SEO as well.

## How to fix

The `<html>` element should have a `lang` or `xml:lang` attribute which describes
the language of the page.

You will usually want to use the `lang` attribute as follows:

```html
<html lang="en-US">
```

(Note this example won't work for XHTML, which is deprecated and highly discouraged).

Make sure you specify a [valid language code](http://www.rfc-editor.org/rfc/bcp/bcp47.txt).

## More information

See [Technique H57](https://www.w3.org/TR/2016/NOTE-WCAG20-TECHS-20161007/H57).

html-lang-required

Most content should be written so people with a lower secondary level of education can understand it.
Where this is not possible, supplemental content or an alternative version should be provided.

This check highlights pages with a reading age of 16 years or higher. Only pages with at least 100 words
of content (excluding navigation, footers, etc) are considered.

For more information, see [WCAG SC 3.1.5](https://www.w3.org/TR/UNDERSTANDING-WCAG20/meaning-supplements.html).

ensure-reading-ability-is-not-advanced

Users must be able to magnify the contents of a web page by up to 200%. In modern
browsers this is almost always possible unless the page chooses to disable it.

Websites should avoid using the meta viewport tag to disable pinch-to-zoom. This behavior
is highly discouraged for accessibility and usability on mobile devices.

Generally the code causing this issue looks like this:

```html
<meta name="viewport" content="width=device-width, initial-scale=1.0, maximum-scale=1.0, user-scalable=no" />
```

Here the use of `user-scaleable=no` asks the browser not to allow user zoom.

iOS no longer allows websites to disable pinch-to-zoom, and ignores this part of the
viewport tag. Therefore to replicate this issue you must use an Android device.

ensure-text-can-resize

Lists of related items should be written [semantically](https://html.com/semantic-markup/) as a
list.

Usually this means rewriting these to use the `<ul>` or `<ol>` tags.

This allows assistive technologies to more easily navigate from item to
item, or past entire groups of links if the user wants to.

## Examples

### Navigation

This navigation:

```html
<a href="/about">About us</a>
<a href="/products">Products</a>
<a href="/contact">Contact us</a>
```

Should be rewritten as a list:

```html
<ul>
  <li><a href="/about">About us</a></li>
  <li><a href="/products">Products</a></li>
  <li><a href="/contact">Contact us</a></li>
</ul>
```

### Tables for content

This single-column table is redundant. There is no
value in placing the content in a table, which makes
it harder for screen reader users to interpret and interact
with.

```html
<table>
  <tr>
    <td>
      Banana
    </td>
  </tr>
  <tr>
    <td>
      Apple
    </td>
  </tr>
  <tr>
    <td>
      Pear
    </td>
  </tr>
</table>
```

Should be rewritten as a list:

```html
<ul>
  <li>Banana</li>
  <li>Apple</li>
  <li>Pear</li>
</ul>
```

## Justification

Users of assistive technologies, like screen readers, can skip an entire
list in one step. In some cases, they can even search inside a list.

These aids are not available where links are written outside a list.
Failing to use lists correctly can force users to have to step through
hundreds of items one at a time.

## Methodology

1. Any single-column tables are automatically considered
   redundant lists.
2. For non-table elements, recursively work down the page looking inside
   each element for links separated by minimal amounts of non-link text.
   If the non-link text is below 30 characters
   in length, we assume we're inside content that should be a list.
   Some exceptions are made, e.g. the presence of an `<hr>` would break
   out of the list.

## More information

See [Technique
H48](https://www.w3.org/TR/2016/NOTE-WCAG20-TECHS-20161007/H48) for
details.

mark-navigation-section-as-list

Images should specify appropriate
[alternative text](https://help.silktide.com/en/articles/8020957-alternative-text),
where appropriate.

Alternative text is text that is used in place of an image if it cannot
be seen. This is important for users who are blind or partially sighted,
who may have the page read to them by a screen-reader. Without alternative
text, they will not know what the image is, or what it is for.

## How to fix this issue

In most cases, you can fix this issue by adding alternative text to the media
in your Content Management System (CMS).

If you need to do this in code, you can alternative text to an image using
the `alt` attribute. For example:

```html
<img src="apple.png" alt="A red apple">
```

Alternative text should be descriptive and useful. We recommend you read
[this comprehensive guide to writing alternative text](https://webaim.org/techniques/alttext/)
by WebAIM.

It is not always appropriate to provide alternative text. For example, if an
image is purely decorative - it adds nothing to the content of the page - then
it is better to omit the alternative text entirely. This is because screen-reader
users will have to listen to the alternative text, which can be annoying if it
is not useful, or highly repetitive.

To specify that an image is decorative, use an empty `alt` attribute, e.g.:

```html
<img src="decorative-image.png" alt="">
```

## Methodology

This check tests if the `alt` attribute is present on an image. If it is not,
then the check fails.

Some images are excluded from this check:

1. **Images without a `src` attribute.** This is because they are
   not visible to users, and therefore do not need alternative text.
2. **Images which are 1px in width or height.** This is because they are only
   used for tracking pixels, or (rarely) layout purposes, and do not need
   alternative text.
3. **Images which are hidden from screen readers using the `aria-hidden` attribute.**
   This is because they are not accessible to screen readers, and therefore would not
   use their alternative text.

## More information

The W3C also provide more information on how to satisfy this check in
[Technique H37](https://www.w3.org/TR/WCAG20-TECHS/H37).

missing-alt

Webpages should provide a way to skip to the main content of the page. There are
several ways to accomplish this.

The most common solution is a "Skip to content" link:

```html
<a href="#main">Skip to main content</a>
...
<div id="main">
<h1>Welcome to this page</h1>
```

This link is usually hidden from users unless selected, so it doesn't need to compromise the look of
your page.

Alternatively, you can use the `<main>` HTML landmark:

```html
<main>
<h1>Welcome to this page</h1>
```

or an ARIA role of `main`:

```html
<div role="main">
<h1>Welcome to this page</h1>
```

Generally best practice is to combine these approaches, using `<main>` landmark with a link pointing to it:

```html
<a href="#main">Skip to main content</a>
...
<main id="main">
<h1>Welcome to this page</h1>
```

This approach will be most widely supported by screen readers and understood by the highest number of users.

# Justification

Many users of assistive technology are only able to experience content sequentially - that is, they must
step through each part of the page, one part at a time. Often this is a slow process, potentially
hampered by a physical impediment.

Most web pages have a header containing branding and navigation on every page. Stepping through
this repetitive part of the page can be hugely frustrating for users of assistive technology. For example,
a blind user may have to listen to hundreds of navigation links before they can reach the content on a page.

Adding a means to skip directly to the page content massively enhances the experience for these users.

Skip to content links do not need to be visible to everyone. A common implementation means they are only
experienced by users via the tab key or other assistive technology
(see [skipping to navigation links](https://webaim.org/techniques/skipnav/) from WebAIM).

# Methodology

It is not sufficient to include a "skip to content" link. The link must work, and it must appear early
enough in the page to be useful.

* If the page has less than 500 visible characters, it does not require a "skip to content" link.
* If the page has a main landmark (e.g. `<main>` or `role="main"`) it does not require a "skip to content" link.
* Silktide looks for a link with a fragment (e.g. `#main`) pointing to a lower part of the page. The link
  must not be adjacent to other text nodes.
* The fragment must point to an ID that exists, or this check will raise an error.
* The link must appear before 500 visible characters of text in the page, or this check will raise an error.

The text inside the link is not considered, as this test must support a wide range of languages.

# Learn more

More about [skipping to navigation links](https://webaim.org/techniques/skipnav/) from WebAIM and
see [W3C's recommended technique](https://www.w3.org/TR/2016/NOTE-WCAG20-TECHS-20161007/G1).

skip-to-content

When viewed on small screens (like mobile phones) content must fit without
requiring scrolling in two dimensions.

WCAG 2.1 specifically requires this for:

+ Vertical scrolling content at a width equivalent to 320 CSS pixels
+ Horizontal scrolling content at a height equivalent to 256 CSS pixels

Except for parts of the content which require two-dimensional layout for usage or meaning,
such as a maps application.

two-dimensional-scrolling

All pre-recorded audio and video should provide appropriate captions. This allows people who are deaf
or hard-of-hearing to use the media.

## Requirements
WCAG requires that captions:

* Represent all spoken dialogue
* Indicate who is speaking, when not visually obvious
* Include important non-speech sounds, like:
  * Laughter
  * Alarms
  * Music lyrics or tone (if meaningful)
  * Sound cues (e.g. _door creaks_)

## What this check looks for

This check identifies video and audio on the page, and checks whether that includes machine-readable captions.

This check will fail if:

* There is a video or audio element that is not muted, and it does not contain a caption track.
* There is a link to a known video platform (such as Vimeo) where captions are not clearly available.

## How this check works

### 1. Videos or audio using HTML5

The check scans for `<video>` and `<audio>` elements directly in the page’s HTML. For each one, it looks at:

* **Whether the media is muted**
  If the media is permanently muted using the muted attribute, the check ignores it. Muted media is assumed not to convey important information through audio.
* **Whether captions are provided**
  The check looks for a <track> element inside the media tag, which is where captions should be included. If no caption track is found, the media fails this check.

Only the first video file source is reported for each video, to avoid confusion from fallback formats.

### 2. Links to external video players

The check also looks for links to known video platforms such as Vimeo. If a link appears to go directly to a video
and there’s no indication that captions are available, the check flags it.

## When captions aren’t needed

If the media is silent, decorative, or doesn’t include any meaningful audio content, then captions may not be
necessary. However, in most cases where information is conveyed through audio, captions must be provided to
meet accessibility requirements.

## Further reading

See [Understanding WCAG Success Criterion 1.2.2](https://www.w3.org/TR/UNDERSTANDING-WCAG20/media-equiv-captions.html).

prerecorded-captions-alternative

Ensure PDF documents are machine-readable for accessibility and usability.

## What this means

A machine-readable PDF is one that can be easily processed by software, such as text-to-speech programs,
search engines, and other data extraction tools. This typically means that the text in the PDF is selectable
and can be copied, as opposed to being embedded as an image.

## Why it matters

1. **Accessibility**: Machine-readable PDFs are essential for people using screen readers or other assistive technologies, as these tools require text they can interpret.
2. **Searchability**: Machine-readable documents can be indexed by search engines, making the content more discoverable.
3. **Content Usability**: Ensuring that your PDFs are machine-readable allows users to interact with the content more effectively, like copying text or searching within the document.

## How to fix

1. **Avoid Scanned Documents**: Whenever possible, create PDFs directly from text-based sources rather than scanning paper documents.
2. **Use OCR on Scanned PDFs**: If you have a scanned PDF, use Optical Character Recognition (OCR) software to convert the image-based text into selectable, searchable text.
3. **Check Font Embedding**: Ensure that all fonts used in the PDF are properly embedded so that the text remains accessible on different devices and platforms.

## Testing Methodology

Silktide examines whether there is selectable text in a PDF to determine if it is machine-readable.

## Further Reading

- [Creating Accessible PDFs](https://www.adobe.com/accessibility/pdf/pdf-accessibility-overview.html)
- [Guide to Machine-Readable PDFs](https://www.webaim.org/techniques/acrobat/)

pdf-not-machine-readable

All controls on the page - including links, buttons, and fields - should clearly
indicate when they have been selected by the keyboard.

This is a stricter version of [WCAG 2.4.7](https://www.w3.org/WAI/WCAG21/Understanding/focus-visible.html),
which requires that the focus indicator is visible, but doesn't specify how clearly
it should be visible.

You can confirm this yourself by loading a webpage and using the Tab key to navigate
through it. Anything you can select should clearly alter its appearance when selected.
For example, a text field might change color, or have a distinctive border applied.

## The requirements

The [official requirements](https://w3c.github.io/wcag/understanding/focus-appearance.html) are
complicated. A simplified version is:

* Surround the control with a solid outline
* The outline must have at least 3:1 contrast with its background
* The outline must have at least 3:1 contrast with its surroundings, or be at least 2px thick

The actual requirements allow for more variation, but generally require that you
calculate the perimeter and/or area of the focus area, which can be very difficult.

## How to fix

Links and form controls should use a focus selector which contrasts with their
unfocused state, as well as any surroundings of the focus state.

In practice, the easiest way to accomplish this is to use a two-color focus, like so:

```css
/* ensure high-contrast mode still has an indicator */
outline: 2px transparent solid;

/* Apply a thick yellow box-shadow with
   a thin dark blue indicator in the middle */
box-shadow: 0 0 0 2px #F9F9D1, 0 0 0 4px #396196, 0 0 4px 8px #F9F9D1;
```

From [Technique C40](https://www.w3.org/WAI/WCAG22/Techniques/css/C40).

Using two contrasting colors guarantees that the focus state will be visible,
regardless of the background or surrounding colors.

## Troubleshooting

### Not enough contrasting pixels change

The [Success Criterion](https://w3c.github.io/wcag/understanding/focus-appearance.html) specifies a minimum area
for the contrasting portion of the focus indicator, which is equivalent to a 2 CSS pixel border around the component.

From the requirements:

> "The easiest and most common way to meet this requirement is to use a solid outline around the component.
> The outline must be at least 2px thick."

In practice, many websites use alternatives to this, such as a thick border along one edge. A problem with
that approach is it is often dependent upon the length of that one edge, which for text links can vary dynamically.

See [Sara Soueidan](https://www.sarasoueidan.com/blog/focus-indicators/#2.-minimum-contrasting-area) for a good
write-up of this concept.

To comply with this Success Criterion, we recommend adding a 2px border around all edges.

Note an earlier draft of this Success Criterion has a more generous allowance here, which is not the case for the
final version.

### Elements appear to change in the browser

Focus states should be defined in CSS alone, and not require JavaScript to work.

Try disabling JavaScript on the page, and see if focus is still visible. If it not,
then the focus state won't work with assistive technologies that don't have a physical
keyboard, e.g. mobile phones.

Some more unusual means of implementing a focus state cannot be detected or measured
automatically. These include:

* Focus implemented via pseudo-elements - such as `::after` or `::before`.
* Focus using `:focus-within` (JavaScript current provides no way to access these).
* Focus cascaded to child elements, e.g. a `<span>` inside an `<a>` tag. We detect
  some of these cases, but there are variations that we cannot detect.

Currently, there is no practical way to assess these focus states automatically.

### Elements over images not analyzed

Silktide cannot assess the contrast of elements that are over images. This is because
the contrast of an element is calculated by comparing the color of the element with the
color of the background.

If the element is over an image, the background color is the
color of the image, which varies from pixel-to-pixel, and may vary further as the page
is resized, due to responsive design.

### Unexpected elements are focusable

You may be surprised to see tags like `<div>` or `<span>` being shown as focusable.
If an element has a `tabindex` of 0 or higher, it becomes focusable. Any HTML tag can be made
focusable in this way, this is so that custom controls (e.g. your own drop-down menus, or
sliders) can support keyboard navigation. [Learn more about tabindex on MDN](https://developer.mozilla.org/en-US/docs/Web/HTML/Global_attributes/tabindex).

## Further reading

* [WCAG 2.4.13](https://www.w3.org/WAI/WCAG22/Understanding/focus-appearance.html)
* [Minimum Contrasting Area explained (Sara Soueidan)](https://www.sarasoueidan.com/blog/focus-indicators/#2.-minimum-contrasting-area)

ensure-focus-appearance

When selecting a user interface component with the keyboard, the focus indicator must
not be _partly_ obscured by anything in front of it.

## Why this matters

When using a keyboard, it is important that the user can see where they are on the page.
If the focus indicator is obscured, the user may not know where they are, and may not
be able to interact with the page.

## Examples

Most common examples include:

* Banners at the top or bottom of the page, such as cookie banners
* Fixed navigation bars
* Fixed footers
* Popup modals, such as cookie consent modals

## Testing this manually

* Open the page
* Press the tab key to move focus through elements on the page
* Check that the focus indicator is not fully obscured by anything in front of it

## Comparison with Level AA version

This is the stricter (Level AAA) version of the Level AA check (2.4.11).

The Level AA version only flags issues where the focus indicator is _completely_ obscured, this
version flags issues where the focus indicator is _partly_ obscured.

## How to fix

With elements that cover part of the screen, such as cookie banners, ensure
that the user can scroll to see any content behind the banner, without having to close
the banner.

The two most very common solutions are:

1. Avoid the use of fixed elements that could obscure other elements
2. Use the CSS `scroll-margin` property (see [WCAG Technique C43](https://www.w3.org/WAI/WCAG22/Techniques/css/C43))

With popup modals, it should usually be impossible to focus anything behind the modal.
Most common modal frameworks will automatically trap focus within the modal, so that
this is impossible. Example: [Bootstrap Modal](https://getbootstrap.com/docs/5.2/components/modal/#live-demo).

## Methodology

1. Silktide simulates a keyboard user tabbing through the page
2. Silktide simulates the focused element being vertically scrolled into the center of the page
   (see 'Rationale for scrolling' below)
3. For each element that receives focus, Silktide checks that the focus indicator is not obscured
   by another element on top of it
4. If the focus indicator is obscured, Silktide raises an issue

### Rationale for scrolling

The rationale for point #2 (above) is worth expanding. At different screen sizes, the amount of scrolling
a browser makes between tabs will vary. For example, Chrome will typically avoid scrolling until a
focus element falls outside the current viewport, and then it will adopt the least amount of
scrolling possible to bring the element into view.

This means if you test a page in Silktide, and in a browser with a fractionally different height,
you may experience different elements being obscured or not, especially elements blocked by sticky headers
and footers. Every only a few pixels of difference in screen height can make a huge difference the
further down the page you go.

In all these cases, the use of user-directed vertical scrolling, e.g. via the cursor keys, would permit
the focused element to be seen. Whether that would be necessary would depend on the exact browser and
size of the browser viewport.

Silktide purposely adopts a generous frame here, to avoid flagging issues which might only affect the
exact screen size that it tested. In our testing, when we didn't do this, the number of subjectively false
positives could be very high, and extremely confusing, as they would not replicate during manual testing on
anything but the exact same browser size.

Essentially, Silktide chooses not to flag issues which _could_ affect some very particular screen sizes
_inconsistently_, but it will flag issues that should affect _all_ screen sizes consistently.

The W3C does not specify how to test this Success Criterion.

### Simulating conditional modals

Silktide adopts additional behavior to simulate the use of dialog modals that may be opened by user
behavior after a page loads (i.e. modals that don't automatically open when a page loads).

If a non-opened modal is detected, Silktide assumes that _elements outside the modal cannot be focused_.
This is not guaranteed, but it is impossible for Silktide to predict the behavior of a modal that has not
yet been opened, and this is much more accurate than assuming that the modal does not constrain focus.

As a result, a modal which is incorrectly programmed (i.e. doesn't constrain focus) may not be detected
as obscuring focus behind it, if the modal is not opened by default.

## Further reading

* [WCAG 2.4.12](https://www.w3.org/WAI/WCAG22/Understanding/focus-not-obscured-enhanced)
* [WCAG Technique C43 - Using CSS margin and scroll-margin to un-obscure content](https://www.w3.org/WAI/WCAG22/Techniques/css/C43)

ensure-focus-is-not-obscured-enhanced

When selecting a user interface component with the keyboard, the focus indicator must
not be _completely obscured_ by anything in front of it.

## Why this matters

When using a keyboard, it is important that the user can see where they are on the page.
If the focus indicator is obscured, the user may not know where they are, and may not
be able to interact with the page.

## Examples

Most common examples include:

* Banners at the top or bottom of the page, such as cookie banners
* Fixed navigation bars
* Fixed footers
* Popup modals, such as cookie consent modals

## Testing this manually

* Open the page
* Press the tab key to move focus through elements on the page
* Check that the focus indicator is not fully obscured by anything in front of it

## Comparison with Level AAA version

This is the less strict (Level AA) version of the Level AAA check (2.4.12).

This Level AA version only flags issues where the focus indicator is _completely_ obscured, the
Level AAA version flags issues where the focus indicator is _partly_ obscured.

## How to fix

With elements that cover part of the screen, such as cookie banners, ensure
that the user can scroll to see any content behind the banner, without having to close
the banner.

The two most very common solutions are:

1. Avoid the use of fixed elements that could obscure other elements
2. Use the CSS `scroll-margin` property (see [WCAG Technique C43](https://www.w3.org/WAI/WCAG22/Techniques/css/C43))

With popup modals, it should usually be impossible to focus anything behind the modal.
Most common modal frameworks will automatically trap focus within the modal, so that
this is impossible. Example: [Bootstrap Modal](https://getbootstrap.com/docs/5.2/components/modal/#live-demo).

## Methodology

1. Silktide simulates a keyboard user tabbing through the page
2. Silktide simulates the focused element being vertically scrolled into the center of the page
   (see 'Rationale for scrolling' below)
3. For each element that receives focus, Silktide checks that the focus indicator is not obscured
   by another element on top of it
4. If the focus indicator is obscured, Silktide raises an issue

### Rationale for scrolling

The rationale for point #2 (above) is worth expanding. At different screen sizes, the amount of scrolling
a browser makes between tabs will vary. For example, Chrome will typically avoid scrolling until a
focus element falls outside the current viewport, and then it will adopt the least amount of
scrolling possible to bring the element into view.

This means if you test a page in Silktide, and in a browser with a fractionally different height,
you may experience different elements being obscured or not, especially elements blocked by sticky headers
and footers. Every only a few pixels of difference in screen height can make a huge difference the
further down the page you go.

In all these cases, the use of user-directed vertical scrolling, e.g. via the cursor keys, would permit
the focused element to be seen. Whether that would be necessary would depend on the exact browser and
size of the browser viewport.

Silktide purposely adopts a generous frame here, to avoid flagging issues which might only affect the
exact screen size that it tested. In our testing, when we didn't do this, the number of subjectively false
positives could be very high, and extremely confusing, as they would not replicate during manual testing on
anything but the exact same browser size.

Essentially, Silktide chooses not to flag issues which _could_ affect some very particular screen sizes
_inconsistently_, but it will flag issues that should affect _all_ screen sizes consistently.

The W3C does not specify how to test this Success Criterion.

### Simulating conditional modals

Silktide adopts additional behavior to simulate the use of dialog modals that may be opened by user
behavior after a page loads (i.e. modals that don't automatically open when a page loads).

If a non-opened modal is detected, Silktide assumes that _elements outside the modal cannot be focused_.
This is not guaranteed, but it is impossible for Silktide to predict the behavior of a modal that has not
yet been opened, and this is much more accurate than assuming that the modal does not constrain focus.

As a result, a modal which is incorrectly programmed (i.e. doesn't constrain focus) may not be detected
as obscuring focus behind it, if the modal is not opened by default.

## Further reading

* [WCAG 2.4.11](https://www.w3.org/WAI/WCAG22/Understanding/focus-not-obscured-minimum)
* [WCAG Technique C43 - Using CSS margin and scroll-margin to un-obscure content](https://www.w3.org/WAI/WCAG22/Techniques/css/C43)

ensure-focus-is-not-obscured-minimum

All controls on the page - including links, buttons, and fields - should show when
they have been selected by the keyboard.

You can confirm this yourself by loading a webpage and using the Tab key to navigate
through it. Anything you can select should alter its appearance when selected.
For example, a text field might change color, or have a distinctive border applied.

This is default behavior for all standard web controls, and so if this issue is appearing
it is because this default behavior has been disabled. Or alternatively, if you have written
your own custom controls, these will need styling to support focus states.

## How to fix

Links and form controls typically define an `outline` CSS style, which ensures
they are highlighted automatically, for example:

```css
input:focus (outline: 2px solid red);
```

If you choose to override or disable the default `outline`, you should specify an accessible
alternative, such as a border or background color.

### Elements appear to change in the browser

Focus states should be defined in CSS alone, and not require JavaScript to work.

Try disabling JavaScript on the page, and see if focus is still visible. If it not,
then the focus state won't work with assistive technologies that don't have a physical
keyboard, e.g. mobile phones.

Some more unusual means of implementing a focus state cannot be detected or measured
automatically. These include:

* Focus implemented via pseudo-elements - such as `::after` or `::before`.
* Focus using `:focus-within` (JavaScript current provides no way to access these).
* Focus cascaded to child elements, e.g. a `<span>` inside an `<a>` tag. We detect
  some of these cases, but there are variations that we cannot detect.

Currently, there is no practical way to assess these focus states automatically.

### Unexpected elements are focusable

You may be surprised to see tags like `<div>` or `<span>` being shown as focusable.
If an element has a `tabindex` of 0 or higher, it becomes focusable. Any HTML tag can be made
focusable in this way, this is so that custom controls (e.g. your own drop-down menus, or
sliders) can support keyboard navigation. [Learn more about tabindex on MDN](https://developer.mozilla.org/en-US/docs/Web/HTML/Global_attributes/tabindex).

## Further reading

* [WCAG 2.4.7](https://www.w3.org/WAI/WCAG22/Understanding/focus-visible.html)

ensure-focus-is-visible

When specifying accessible names via `aria-labelledby`, ensure that the
label elements exist.

## Explanation

Accessible names are required for many parts of a page, including form controls.
One way to accomplish this is to use `aria-labelledby` to specify the ID or IDs of
other elements which contain a label. For example:

```html
<h2 id="dialog-labell">Important message!</h2>
<dialog aria-labelledby="dialog-label">
```

In this example, the `aria-labelledby` for the `<dialog>` points to an ID of `dialog-label`,
which doesn't exist. The heading it refers to instead has an ID of `dialog-labell`, presumably
a typo.

## Why this matters

It isn't usually clear when an accessible name is broken, even during user testing.

This check helps to identify where an element clearly intended to have a label, but
that label is missing.

When a label is broken, it may be impossible for a user of assistive technologies
to understand what that element does.

missing-aria-labelled-by

Tables which contain information should have clear headers defined.

In this example, the top row of the table is a header:

| Surname        | City          |
| -------------- | ------------- |
| Washington     | London        |
| Phoenix        | Arizona       |
| Austin         | Travis        |

Notice how without the header here, it would be almost impossible to understand
what the individual values mean ("Washington" could be a city or a surname).

It is not enough to just make the headers look differently, as accessible technologies will not
recognize this (for example, a screen reader cannot 'see' different colors or fonts).
Table headings must be defined using the `<th>` tag.

This example shows how a table should use a `<th>` to mark cells as headings. Note the
use of the `col` attribute, to specify these headings are for the _column_:

```html
<table>
  <tr>
    <th scope="col">First name</th>
    <th scope="col">City</th>
  </tr>
  <tr>
    <td>Washington</td>
    <td>London</td>
  </tr>
  <tr>
    <td>Phoenix</td>
    <td>Arizona</td>
  </tr>
  <tr>
    <td>Austin</td>
    <td>Travis</td>
  </tr>
</table>
```

Tables which are used purely for layout do not need to do this. However,
[the use of tables for layout is strongly discouraged](https://www.lifewire.com/dont-use-tables-for-layout-3468941).
This check will ignore tables that it believes are purposely used for layout.

Learn more about [accessible table design (W3C)](https://www.w3.org/WAI/tutorials/tables/one-header/).

add-header-to-tables

Lists (e.g., `<ul>` or `<ol>`) should only contain list items (`<li>`) as a direct descendant
to ensure that screen readers can accurately report the amount of items contained in the list.

## Example

In the following example, some screen readers would say this list has two items, instead of
four:

```html
<ul>
    <div class="some_class">
        <li>Example 1</li>
    </div>
    <div class="some_other_class">
        <li>Example 2</li>
        <li>Example 3</li>
        <li>Example 4</li>
    </div>
</ul>
```

To fix this, you would need to remove the `<div class="some_class">` and
`<div class="some_other_class>` elements and ensure only `<li>` list items remain.

## Further reading

The [formal specification for the list element](https://developer.mozilla.org/en-US/docs/Web/HTML/Element/ul)
shows what is and is not permitted inside an `<ul>` and `<ol>`.

See [Technique H88](https://www.w3.org/TR/WCAG20-TECHS/H88.html) for more information.

Priority	Recommendation	Progress
	Ensure interactive components are far enough apart WCAG 2.2 AA 2.5.8	3.8%
	Ensure links explain their purpose WCAG 2.0 A 2.4.4	0%
	Ensure form controls have labels WCAG 2.0 A 1.3.1	24%
	Identify the purpose of fields programmatically WCAG 2.1 AA 1.3.5	16%
	Ensure form controls contrast sufficiently with their surroundings WCAG 2.1 AA 1.4.11	23%

Johnson Controls

Accessibility

WCAG Levels

Recommendations

The best free accessibility checker
